Technical Data

Model	DEC 450 L	DEC 500 L
A (mm)	1600	1800
B (mm)	4500	5000
C (mm)	1400	1600
D (mm)	4500	5000
E (mm)	3000	3500
Dimensions Diagram	View	View
Weight (kg)	640	700
Hydraulic System	DEC 450L	DEC 500L
Oil Tank Capacity (lt/min)	110	110
Hydraulic Oil (type)	ISO-L-HM 68	ISO-L-HM 68
Head	DEC 450L	DEC 500L
G-Working Width (mm)	800-1000	800-1000
Weight (kg)	100-120	100-120
Rotor Speed (rpm)	2800	2800
Rotor Power (hp)	29-47	29-47
Tractor	DEC 450 L	DEC 500 L
Min Power Requirements (hp)	55	55
Min Weight (kg)	2500	2800
PTO Speed (rpm)	540	540

Flail Hedge Mower Arm Motion

Data/Model	DEC 450 L	DEC 500 L
Arm Motion
A (mm)	1600	1800
B (mm)	4500	5000
C (mm)	1400	1600
D (mm)	4500	5000
E (mm)	3000	3500
Dimensions Diagram (click to view)	View	View
Weight (kg)	640	700
Hydraulic System
Oil Tank Capacity (ltr)	110	110
Hydraulic Oil (type)	ISO - L - HM 68	ISO - L - HM 68
Head
G-Working Width (mm)	800 - 1000	800 - 1000
Weight (kg)	100 - 120	100 - 120
Rotor Speed (rpm)	2800	2800
Rotor Power (hp)	29 - 47	29 - 47
Tractor
Min Power Requirements (hp)	55	55
Min Weight (kg)	2500	2800
PTO speed (rpm)	540	540

Features & Options

Piston Motor

Support Stretchers

Electric Control Joystick

Heat Exchanger

Tractor Stabilisers – P.T.O Drive Shafts

Distributor With Reversal Prevention Lever

Floating Ground Self Levelling System

Cast-Iron Engine

Two-Way Head Operation
