Technical Data
| Data/Model | MT1800 | MT1800H |
|---|---|---|
| ENGINE | ||
| Engine | 18 hp Water-Cooled Diesel | 18 hp Water-Cooled Diesel |
| PTO HP | 16 hp | 16 hp |
| No. of Cylinders | 3 | 3 |
| Displacement | 952 cc | 952 cc |
| Rated RPM | 2,600 rpm | 2,600 rpm |
| FUEL SYSTEM | ||
| Fuel Capacity | 13 litre | 13 litre |
| Injection Type | I.D.I | I.D.I |
| Engine Shut-Off | Key | Key |
| DRIVETRAIN | ||
| Transmission Type | Gear | HST |
| Speeds | 6F-2R | 2 Range |
| Brakes | Wet Disc | Wet Disc |
| HYDRAULICS | ||
| Position Control | Standard | Standard |
| Draft Control | Option | Option |
| Main Pump Capacity | 17.1 litre/min | 17.1 litre/min |
| Maximum Pressure | 145 kgf/cm2 | 145 kgf/cm2 |
| Steering Pump Capacity | 8.6 litre/min | 8.6 litre/min |
| Maximum Pressure | 105 kgf/cm2 | 105 kgf/cm2 |
| Auxiliary Valve | Option | Option |
| PTO | ||
| Type | Trans | Live |
| Rear PTO RPM | 540/2376 rpm | 540/2376 rpm |
| Rear PTO Shaft Size | 35-6 splines | 35-6 splines |
| Mid PTO | Option (2000/2556 rpm) | Option (2000/2556 rpm) |
| Mid PTO Shaft Size | 25.4-15 splines | 25.4-15 splines |
| STEERING | ||
| Power Steering | Hydrostatic (Standard) | Hydrostatic (Standard) |
| Turning Radius (AG Tyres W/Brake) | 2.0 m | 2.0 m |
| HITCH Type | Category 1 | Category 1 |
| Lift Capacity at Hitch Point | 635 kgf | 635 kgf |
| TYRES | ||
| AG Tyres Front | 5-12, 4PR | 5-12, 4PR |
| AG Tyres Rear | 8-16, 4PR | 9.5-16, 4PR |
| AG Tyres Front | 5-12, 4PR | 5-12, 4PR |
| AG Tyres Rear | 9.5-16, 4PR | 9.5-16, 4PR |
| Turf Tyres Front | 23 x 8.5-12 | 23 x 8.5-12 |
| Turf Tyres Rear | 315/75D15 | 315/75D15 |
| DIMENSIONS (W/AG Tyres) | at 8-16 | at 9.5-16 |
| Wheelbase | 1,450 mm | 1,450 mm |
| Overall Width | 1,055 mm | 1,170 mm |
| Overall Length | 2,570 mm | 2,570 mm |
| Height (Top of ROPS) | 2,300 mm | 2,330 mm |
| Ground Clearance | 290 mm | 310mm |
| Weight | 680 kg | 730 kg |
Features
- 1
- 2
Engine
Powerful 3 cylinder, water-cooled diesel engine giving dynamic power, stable…
Transmission
All models are available in either gear or hydrostatic drive.
External Hydraulic
External hydraulic block for easy connecting to hydraulic operating implements…
Steering
Easy adjusting tilt steering making it more comfortable to operate.
Deluxe Seat
Large and spacious deluxe seat makes operating a comfortable experience.
ROPS
The foldable Roll Over Protection Structure (ROPS) adjusts to 3 positions enabling…
