Technical Data
| Data/Model | MT36 | MT36H |
|---|---|---|
| ENGINE | ||
| Model | S3L3L | S3L3L |
| Engine | 4 Cycle Water Cooled Diesel | 4 Cycle Water Cooled Diesel |
| Max Output PS(kW)/rpm | 36.2(27.0)/2600 | 36.2(27.0)/2600 |
| PTO HP | 28 hp | 27.5 hp |
| No. of Cylinders | 3 | 3 |
| Displacement | 1662 cc | 1662 cc |
| FUEL SYSTEM | ||
| Fuel Capacity | 24.5 litre | 24.5 litre |
| Injection Type | I.D.I | I.D.I |
| Engine Shut-Off | Key | Key |
| DRIVETRAIN | ||
| Transmission Type | Gear | HST |
| Speeds | 8F-8R | 3 Range |
| Shuttle (F&R) | Synchro | N/A |
| Brakes | Wet Disc | Wet Disc |
| HYDRAULICS | ||
| Position Control | Standard | Standard |
| Draft Control | Option | Option |
| Main Pump Capacity | 29 litre/min | 29 litre/min |
| Steering Pump Capacity | 12.7 litre/min | 12.7 litre/min |
| Auxiliary Valve | Option | Option |
| PTO | ||
| Type | Independent | Live |
| Rear PTO RPM | 540/1000 | 540 |
| Mid PTO | N/A | Option (2000) |
| STEERING | ||
| Power Steering | Hydrostatic (Standard) | Hydrostatic (Standard) |
| Turning Radius (AG Tyres W/Brake) | 2.4 m | 2.4 m |
| HITCH | ||
| Type | Category 1 | Category 1 |
| Lift Capacity at Hitch Point | 1,200 kgf | 1,200 kgf |
| TYRES | ||
| AG Tyres Front | Jul-16 | Jul-16 |
| AG Tyres Rear | 12.4-24 | 12.4-24 |
| Turf Tyres Front | 212/80D15 | 212/80D15 |
| Turf Tyres Rear | 355/80D20 | 355/80D20 |
| DIMENSIONS at 7-16/12.4-24 (W/AG Tyres) | ||
| Wheelbase | 1,750 mm | 1,750 mm |
| Overall Width | 1,400 mm | 1,400 mm |
| Overall Length | 3,190 mm | 3,190 mm |
| Height (Top of ROPS) | 2,410 mm | 2,410 mm |
| Ground Clearance | 330 mm | 330 mm |
| Weight | 1,205 kg | 1,210 kg |
Features
- 1
- 2
High Clearance
Operates with ground clearance of 290mm with AG Tyres.
Clutch
One touch independent PTO clutch. (28/36 horsepower only).
High Lift Capacity
High lift capacity – 3 point linkage.
Pump
Large capacity hydraulic pump generates additional power for larger lawn and…
ROPS
The foldable Roll Over Protection Structure (ROPS) adjusts to 3 positions enabling…
Deluxe Seat
Large and spacious deluxe seat makes operating a comfortable experience.
Steering
Easy adjusting tilt steering making it more comfortable to operate.
External Hydraulic
External hydraulic block for easy connecting to hydraulic operating implements…
Transmission
All models are available in either gear or hydrostatic drive.
Engine
Powerful 3 cylinder, water-cooled diesel engine giving dynamic power, stable…
